Our Gallery
A glimpse into our world—our projects, our people, and our progress.
Air Sampler
Developed for Galleon. Designed with a touch-screen interface featuring secure user login, user privilege management, and calibration functions. Allows selection of air sample volume and supports online sampling operations. Maintains audit trail and sample records with full traceability. Generates audit and sample reports through dedicated report software.
2 Channel Stepper Motor Controller
2-Channel Stepper Motor Controller developed for Fourvac Technologies. Motor speed and postion control via touchscreen and HMI. Sequential motor operation with position feedback through pulses encoders. Equiped with a commands set for compute communication and a graphical user interface.
Desiccant Dryer Mobile-PCB
Developred for Labotek, India. Used in drying and conveying system application.
Phase Detector
Phase Detector developed for Labotek, India. Developed for Labotek, India. Monitors 3-phase supply (R, Y, B) for faults. Detects phase failure, phase reversal.
Microscan
Developed for Labotek. 8-channel automatic controller of conveying of rew materials.
Con-Evator
Developed for Labotek, India. Used in plastic industry for conveying of plastic granular materials. New feature added to control card through android application.
Hand Held Controller for Leak Detector
Developed for Fourvac Technologies. It is wired utility for Healium Leak Detector to read leak rate, status, to start and stop leak detection operations.
Weigihng Scale Indicator
Engineered for industrial weighing applications demanding high accuracy and long-term reliability, featuring a calibrated 4–20 mA analog output proportional to weight for direct integration with PLCs and control systems.
Compressed Air Dryer Controller
Developed for Labotek, India Used in Compressed Air Dryer New feature added to control the card through Android Application.
6 Channel Relay Controller
6-Channel Relay Controller developed for New Magnetic Sources. Features precise control logic for industrial applications.
MTC
MTC developed for Labotek, India. Used in mold temperature control applications. It has provision to connect temprature, flow and pressure sensors.
Single Channel Controller
Developed for Fourvac Technologies. Motor speed and position control via touchscreen. HMI.Sequential motor operation with position feedback through pulses or encoders. Equipped with a command set for computer communication and a graphical user interface.
Isolator
Isolator Controller developed for Fourvac Technologies. Features advanced isolation techniques for industrial applications.
Delay
Delay Timer developed for Labotek, India. The delay unit provides a fixed 3-second time delay on power-on/reset before activating the output relay. This prevents false triggering and protects connected equipment from transient conditions during startup. The unit is reliable, industrial-grade, and suitable for automation and control applications.
Humidifier Controller
Developed for Satellite Application Centre (SAC) Ahemdabad Used to increase the Humidity of Dry Chamber if chamber humidity is less than set humidity.
DH3
Developed for Labotek,India. Used for drying of granular materials. The PCB accepts temperature setpoint through an external 4–20 mA input mapped to 20–200 °C and provides a 4–20 mA output proportional to the actual temperature.
3S-Timer
3-A dedicated Timer PCB developed for Technotrend Innovations Pvt. Ltd., specifically designed for drying applications.
EPS Wave Soldering Machine
Dual solder wave machine, 300mmx 300mm PCB capacity, Foam flux bubbler, Carrier conveyor and Finger conveyor, Slide-out foam fluxer with drip tray, Lead free (ROHS) solder bath available, Well maintained and calibrated
Pick and Place Machine
Maximum board area 400mm X 300mm, Mounting speed 4000cph, Component placement accuracy ±0.05mm, In built suction and blow, Component sizes applicable: 0402, 0603, 0805, 1206, 1210, diodes , transistor, QFP16x16mm, 32 nos of feeder slots, 2 mounting heads, vision camera, 0 to 360 degrees component angle
EPS Reflow Oven
Maximum board area 400mm X 300mm, Mounting speed 4000cph, Component placement accuracy ±0.05mm, In built suction and blow, Component sizes applicable: 0402, 0603, 0805, 1206, 1210, diodes , transistor, QFP16x16mm, 32 nos of feeder slots, 2 mounting heads, vision camera, 0 to 360 degrees component angle
Ultrasonic Cleaner
Capacity 5L, Stainless Steel, Temperature upto 40°C, Ultrasonic Frequency 30KHz
